SB reeflights.

Discussion in 'LED Lighting Specific' started by USMC4Life, Dec 31, 2016.

  1. kevlow

    kevlow Member

    Joined:
    Feb 18, 2011
    Messages:
    23
    Likes Received:
    44
    Location:
    clearwater, fl.
    Agreed. Good observation. My blues tend to photograph as purple.

  2. USMC4Life

    USMC4Life Well-Known Member

    Joined:
    Sep 27, 2015
    Messages:
    503
    Likes Received:
    283
    Location:
    NJ
    Congratulations!

    dave57 likes this.
  3. dave57

    dave57 Well-Known Member

    Joined:
    Feb 25, 2016
    Messages:
    71
    Likes Received:
    75
    What are your setting? Have you measured par levels on your tank? Looks nice

  4. kevlow

    kevlow Member

    Joined:
    Feb 18, 2011
    Messages:
    23
    Likes Received:
    44
    Location:
    clearwater, fl.
    Thank you.
    Blue/purple set at 100% and whites/red at 50%. I keep my fixture up high at 16 inches above the water so that I get good spread and even color blending. I was nervous about the disco light effect but I have not experienced this at all.

    I borrowed a par meter recently. My numbers are consistent because my tank is so shallow. The center 14 inches running the length of the tank between my overflows is 400-450 par. The next 2-3 inches outward is 250-350 or so. 1-2 inches out from the front and back glass is 100-200.

    Have a shallow display 48x24x8 means I must think in terms of spread from center instead of depth to get varying degrees of par. Depth is something I don't have. The 32 SBLights is perfect shape for my tank. My Radions did not work well because of their puck design. To get spread I had to raise them to the point that I had low par, 100-275 running at 100% all channels. I would have needed three, maybe four Radions to get coverage and lower them for more par. I already owned two was not about to double my investment.

    The SB Lights are giving much better par, much better coverage, and consequently better growth and color. Which is impressive because I personally believe that lighting can be flexible and is not near as important as water quality.

    prsnlty, dave57 and USMC4Life like this.
  5. USMC4Life

    USMC4Life Well-Known Member

    Joined:
    Sep 27, 2015
    Messages:
    503
    Likes Received:
    283
    Location:
    NJ
    The sb light I have is crazy bright. But then the par meter I have is not exactly up to par. (All pun intended) IMG_1484178011.921058.jpg

    saltyfilmfolks, prsnlty and dave57 like this.
  6. dave57

    dave57 Well-Known Member

    Joined:
    Feb 25, 2016
    Messages:
    71
    Likes Received:
    75
    I just bought myself two sb reef lights I like them. I'm just wondering what par levels I should maintain them at. I have sps.. idk if you guys have seen dan riddles speech at macna 2016 regarding lighting, alk and flow and how they correlate with growth. He suggests having par levels at around 200 for increased photosynthesis.. vs high levels above 300.. have you guys looked into that?


    saltyfilmfolks, prsnlty and USMC4Life like this.
  7. kevlow

    kevlow Member

    Joined:
    Feb 18, 2011
    Messages:
    23
    Likes Received:
    44
    Location:
    clearwater, fl.
    I have not read this but my understanding of this subject and personal experience has led me to this: That higher par requires higher nutrients and lower alk. Lower par allows for lower nutrients and higher alk.
    In my own tanks with my husbandry practices, acros did not grow well in 175-275 par. They did not color up either but rather stayed a tan/brownish/mauve color.
    I do believe that it is all an equation and a balancing act. Every tank is different and as soon as you change one parameter then the entire equation changes. Hence every tank works a little different. It is up to me to find the correct balance of food and alk to go with the light and flow in my system.

    dave57 likes this.
  8. dave57

    dave57 Well-Known Member

    Joined:
    Feb 25, 2016
    Messages:
    71
    Likes Received:
    75


    Check it out let me know what you think


  9. USMC4Life

    USMC4Life Well-Known Member

    Joined:
    Sep 27, 2015
    Messages:
    503
    Likes Received:
    283
    Location:
    NJ
    The output of par and spectrum of SB light is exceptional. That aside it will depend on the depth of your tank and how you game them setup. I would say take about two weeks to ramp them up to 70% on white. And about the same on blue. But be careful on UV. Ramp it up slow. And I would say go by how the coral react.

    saltyfilmfolks likes this.
  10. kevlow

    kevlow Member

    Joined:
    Feb 18, 2011
    Messages:
    23
    Likes Received:
    44
    Location:
    clearwater, fl.
    Lots of info!
    The simplified version that I can grasp is that Low par and high alk can both produce faster growth.
    Higher par produces color.

    I think that having a bacteria driven tank [eating up and lowering nutrients], reducing Zooxanthellae [getting rid of brown protective coloring], causes an acropora coral to develop it's own pigments to protect it from the high par.

    The trade off is that having colorful acros is at the expense of really fast growing brown corals. Once the brown colored Zooxanthellae have been reduced then the rate photosynthesis reduces also.

    I think the ultimate goal, the holy grail of sps keeping is to have fast growth and incredible color. The people that achieve this have found the balance of reducing the Zooxanthellae, inducing pigmentation, all while pumping enough nutrients and bacteria through to keep the coral growing [ but not enough to cause a bloom in the brown Zooxanthellae].

    This is about all that I am able to wrap my brain around.

    dave57 and saltyfilmfolks like this.
  11. saltyfilmfolks

    saltyfilmfolks Lights! Camera! Reef! R2R Supporter R2R Excellence Award Reef Squad

    Joined:
    Feb 25, 2014
    Messages:
    9,325
    Likes Received:
    7,105
    Location:
    California
    B I N G O
    both work. I prefer higher levels simple because it seems to reduce nutrient issues. IE the corals are eating the food faster.

    Keep in mind, as it was discussed after they turned the cameras off,(I was there) this is a singular data point and not a rule. Use the data point to manipulate the outcome and understand the out come. This Is what I believe what kevlow was illustrating.

    Acclimation IS KEY. Why? your increasing and decreasing the organisms(animals) metabolism. Targeting the 250 to 300 is a good starting point, then go from there while you play experiment and learn. this is part of the why many say go SLOOOOW.

    And for many who have different rock work, it is impossible to distribute light evenly(its not a frag tank), so be the nature of it some will get low ligh some high. And back to old scool rules, its why you start on the bottom and move up, as the field of light in a tank can vary by as much a 400 par.+ depending on the depth.

    dave57 likes this.
  12. dave57

    dave57 Well-Known Member

    Joined:
    Feb 25, 2016
    Messages:
    71
    Likes Received:
    75
    I tried ramping up the blues to 100% and have whites at 10 percent so far I'm getting around 450 par at the top of my corals. I feel like if I start adding more white I'm going to bleach my corals.. they were accustomed to 250-300 par.. we'll see how things go in the next couple of weeks.



    saltyfilmfolks likes this.
  13. saltyfilmfolks

    saltyfilmfolks Lights! Camera! Reef! R2R Supporter R2R Excellence Award Reef Squad

    Joined:
    Feb 25, 2014
    Messages:
    9,325
    Likes Received:
    7,105
    Location:
    California
    IMO consider PUR. do the corals like that much blue. Ie old school 14k MH v 20 MH. With only blue you may be giving the 32k.
    I would experiment with combos of white blue, and Id assume you can reach 450 using different color ratios.
    Thus, why I usually recommend setting by eye, and then intensity.

  14. dave57

    dave57 Well-Known Member

    Joined:
    Feb 25, 2016
    Messages:
    71
    Likes Received:
    75
    It appears really blue on photograph but it's very similar to 20k from my radions. For some reason the sb reef lights photograph very purple/blue these sb reef lights are so strong if I increase whites just a little par jumps like crazy, I can possibly try a 50w/20 white hmm let me get my par meter out

    saltyfilmfolks likes this.
  15. saltyfilmfolks

    saltyfilmfolks Lights! Camera! Reef! R2R Supporter R2R Excellence Award Reef Squad

    Joined:
    Feb 25, 2014
    Messages:
    9,325
    Likes Received:
    7,105
    Location:
    California
    there is soo much burple in these lights. I kinda like it but...

    Also a FWIW, manufacturer color schemes differ.
    White. May be 8k or 14k depends.
    Blue, may be 20k or higher, OR, may be only 420 to 460 and NOT a true color temp. just a piece of the spectrum that allows mixing channels to achieve an actual color temp.

  16. dave57

    dave57 Well-Known Member

    Joined:
    Feb 25, 2016
    Messages:
    71
    Likes Received:
    75
    50b/20w about 300 par above the corals
    I'll bump blue to 75/30w
    50/20
    75/30. 400 par

    kevlow likes this.
  17. dave57

    dave57 Well-Known Member

    Joined:
    Feb 25, 2016
    Messages:
    71
    Likes Received:
    75
    I feel like the 75/30 is a good combo it reduces a lot of the shadowing with increased white.. but still appears burple like you said.. just slight differences

    saltyfilmfolks likes this.
  18. prsnlty

    prsnlty Jackie R2R Supporter

    Joined:
    Jun 22, 2011
    Messages:
    4,480
    Likes Received:
    615
    Location:
    Citrus Co, Florida
    What's the distance between the corals and light at 300 par?

    saltyfilmfolks likes this.
  19. prsnlty

    prsnlty Jackie R2R Supporter

    Joined:
    Jun 22, 2011
    Messages:
    4,480
    Likes Received:
    615
    Location:
    Citrus Co, Florida
    Check out this video. Great info to help you with deciding on your settings.

    dave57 likes this.
  20. dave57

    dave57 Well-Known Member

    Joined:
    Feb 25, 2016
    Messages:
    71
    Likes Received:
    75
    16 inches deep measuring from the light 7 inches above water. So from light to above corals it's 16 inches.

    prsnlty likes this.
